    Networking Circuit Protection Fuses 10A 20A Resettable Fuse 0451010.MRL

    Ask Lasest Price
    Brand Name : Littelfuse
    Model Number : 0451010.MRL
    Price : Negotiable
    Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram
    Supply Ability : Available Quantity 300000 Pieces
    Delivery Time : Negotiable
    • Product Details
    • Company Profile

    Networking Circuit Protection Fuses 10A 20A Resettable Fuse 0451010.MRL

    Surface Mount Fuses Circuit Protection 0451010.Mrl Littelfuse 10a 20a Fuse 125V


    Product Range
    • The Nano2® SMF Fuse is a very small, Wire-in-Air (WIA) square shape surface mount fuse that was designed for secondary side circuit over-current protection applications. These fuses are designed for PCB using surface mount technology
    App Characteristics
    • Very fast-acting
    • Small size
    • Wide range of current rating available (0.062A to 20A)
    • Wide operating temperature range
    • RoHS compliant and Halogen Free
    • UL Listed and Recognized to UL/CSA/NMX UL 248-1 and UL/CSA/NMX UL 248-14 (see Agency Approvals)
    • Conforms to DENAN’s Appendix 3
    • Conforms to IEC/EN 60127-1 and IEC/EN 60127-7
    Basic Data

    Internal Part Number0451010.MRL
    Lead Free Status / RoHS StatusLead free by exemption / RoHS Compliant
    Moisture Sensitivity Level (MSL)1 (Unlimited)
    Production Status (Lifecycle)In Production
    ConditionNew & Unused, Original Sealed
    Product Training ModulesFuseology - Introduction to Fuses
    EDA / CAD ModelsDownload from Accelerated Designs
    Standard Package1,000
    CategoryCircuit Protection
    FamilyFuses
    SeriesNANO²® 451
    PackagingTape & Reel (TR)
    Fuse TypeBoard Mount (Cartridge Style Excluded)
    Current Rating10A
    Voltage Rating - AC125V
    Voltage Rating - DC125V
    Response TimeFast
    Package / Case2-SMD, Square End Block
    Mounting TypeSurface Mount
    Breaking Capacity @ Rated Voltage35A AC, 50A DC
    Melting I²t26.46
    ApprovalsCSA, PSE, UL
    Operating Temperature-55°C ~ 125°C
    Color-
    Size / Dimension0.240" L x 0.106" W x 0.106" H (6.10mm x 2.69mm x 2.69mm)
    DC Cold Resistance0.0056 Ohm
    Weight0.001 KG
    ApplicationEmail for details
    Alternative Part (Replacement)0451010.MRL
    Related Links04510, 0451010.MRL Datasheet, Littelfuse Distributor
    DOWNLOAD DATASHEET
    Application
    • Notebook PC
    • LCD/PDP TV
    • LCD monitor
    • LCD/PDP panel
    • LCD backlight inverter
    • Portable DVD player
    • Power supply
    • Networking
    • PC server
    • Cooling fan system
    • Storage system
    • Telecom system
    • Wireless basestation
    • White goods
    More Surface Mount Fuses Models
    0451010.Mrl0157010.DR0154.062DR0154.315DR0154003.DR
    0154002.DR0154004.DR0154003.DRT015401.5DR015402.5DR
    0154008.DR0154007.DR0154005.DR0154004.DRT0154001.DRT
    0157005.DRT015402.5DRT0157002.DR0157003.DR0154004.DRL
    0456030.ER0461002.ER0463020.ER0456025.ER04611.25ER
    0476001.MRSN0461.500ER0443005.DR046406.3DR0443004.DR
    Chip Diagram

    Networking Circuit Protection Fuses 10A 20A Resettable Fuse 0451010.MRLNetworking Circuit Protection Fuses 10A 20A Resettable Fuse 0451010.MRLNetworking Circuit Protection Fuses 10A 20A Resettable Fuse 0451010.MRL
